ZTE ZXA10 C320 Chassis with 2xSMXA (UCDC1) DC

Ask Lasest Price
Brand Name :	HONGKING
Model Number :	C300
Supply Ability :	10000pcs/Week
Price :	Negociatable
Certification :	CE ROHS Anatel
Delivery Time :	7-15days
Payment Terms :	T/T,Western Union

Add to Cart

Product Details
Company Profile

ZTE ZXA10 C320 Chassis with 2xSMXA (UCDC1) DC

ZXA10 C320 Dual GE DC

ZTE ZXA10 C320 Chassis with 2xSMXA (UCDC1) DC

Description:

ZTE ZXA10 C320 Chassis with 2xSMXA (UCDC1 pinch card embedded) GE Main Control Board with DC power port integrated

Overview

ZTE ZXA10 C320 19-inch Chassis equipped with 2xSMXA (UCDC1 pinch card embedded, DC power port)
Comes with 2PCS DC power cables, 1PCS earth cable
ZXA10 C320 Chassis with 2xSMXA (UCDC1) equipped
2 service slots

ZTE ZXA10 C320 Chassis with 2xSMXA (UCDC1) DC

Configuration
Main Control Board			SMXA: 2
Pinch Card			UCDC1: 2 Provide total 4 GE uplink ports
GPON Ports			0
Service Slots Remain			2
Power Supply Mode(W)			DC power supply: -48V+/-20%, -60V+/-20%
Device Specifications
Dimensions (mm)			86.1(H) × 482.6 (W) × 270 (D)
Weight(kg)			4.5

Key Features
Unified platform for GPON,XG-PON1 and P2P
Small size andcompact design, flexible network and fast deployment
2U frame with 2 service slots, compatible with ZXA10 C300 line cards
Abundant service support capability: IPTV, VoIP, HSI, VPN, mobile backhaul, etc
Higher security assurance: ONT authentication, user ID identification, port isolation, address binding, packet filtering, and
broadcast packet suppression.
High reliability: key parts redundancy; support Type B and Type C protection for PON downlink and LACP/ UAPS/STP/ERPS for uplink
Service differentiation: Comprehensive QoS mechanisms for voice, video and high speed Internet services.
Support DC input redundancy
Support AC power supply
Support 1:1 protection for PON interfaces
Support 1:1 protection for SW (core card) card
Support 1588V2 and Synchronous Ethernet
Support embedded OTDR in SFP
System Architecture
Capacity
GPON up to 32 ports
Uplink interfaces up to 4 *GE (Optical )+2*GE(Electronic) or 2*10GE(Optical )+2*GE(Optical ) +2*GE(Electronic)
Chassis Configuration (19")
Total 5 slots
2 slots for universal line cards
2 slots for switch& control cards
1 slot for fan module
Subscriber Card Density
GPON card: 8/16 ports per card
XG-PON1 card: 8 ports per card
P2Pcard: 24/48 ports per card
Uplink interface card
1*10GE optical port ( Configurable 1*GE optical port)
1*GE optical port
1*10 M/100 M/1000 M electrical Ethernet port
Common interfaces
1*environment detecting interface
1*management interface
1*maintenance serial interface
PON Features
GPON compliant with ITU G.984.x
P2P compliant with ITU G.985/G.986
XG-PON1 compliant with ITUG.987.x andG.988
Support 1:128 optical split ratio for xPON
Support OLS (Optical Laser Supervising )
Max logical reach: 60km
Max physical reach: 20km
Max link difference: 20km
High-efficient DBA: NSR-DBA,SR-DBA
Synchronous Ethernet
GPON Transceiver power: Class B+ or class C+
XG PON1 Transceiver power: Class N1 and N2a TypeB and type C optical uplink protection
Support FEC
Support AES128
Support SCB
GPON MCM(Multi-Copy Multicast)
Support 1550nm for third party CATV broadcasting
L2/L3 Features
4K VLAN
1:1/N:1 VLAN
