Huawei MA5608T chassis with 2xMCUD1, 1xMPWD, 2xGPFD C+ SFP ModuleHuawei MA5608T equipped with 2xMCUD1 (2xGE SFP+2xGE/10GE SFP+
Uplink, include 2 GE SFP Module) 1xMPWD AC Power Module, 2xGPFD C+
Comes with 2 PCS power cable, 1 PCS earth cable, 2 PCS mount ear,
accessory package
MA5608T chassis
2 MCUD1 equipped, switching capacity 256Gbit/s active/standby mode
1 MPWD equipped, input AC voltage: -100 V to -240 V
2 GPFD equipped, with 16 C+ SFP ModuleMA5608T Dual 10GE AC 32GPON C+ bundle configuration,is recommended board bundle provided by hongking communication, it
has most common service type and ordinary. welcome to contact us
for customized configuration you need.Huawei SmartAX MA5608T GPON OLT, 19 inch, with 2U height 2 service
slots, support EPON, GPON, 10G PON, P2P, xDSL and POTS; H801MABR
subrack
| Product Name | OLT Service Subrack |
| Brand | Huawei |
| Mode | MA5608T |
| Packing Size | 59x38.5x18 |
| Gross Weight | 12 |
| Service Board Slots | 2 |
| Interface Board | MCUD+GPFD |
Pls Confirm with our saler the specification you need| MA5608T OLT 1xMCUD + 1xMPWC |
| MA5608T OLT 1xMCUD + 1xMPWD |
| MA5608T OLT 1xMCUD1 + 1xMPWC |
| MA5608T OLT 1xMCUD1 + 1xMPWD |
| MA5608T OLT 2xMCUD + 1xMPWC |
| MA5608T OLT 2xMCUD,1xMPWD |
| MA5608T OLT 2xMCUD1 + 1xMPWC |
| MA5608T OLT 2xMCUD1 + 1xMPWD |
The MA5608T, if serving as a mini OLT, supports GPON, 10G GPON, and
P2P access modes. It can be installed at a residential district or
a street side, which reduces the usage of ODN backbone optical
cables, lowers the ODN deployment cost and difficulty, and
minimizes the CO equipment room space.
The MA5608T, if serving as a mini-DSLAM, supports ADSL2+, VDSL2,
SHDSL, and POTS access modes and provides Internet access, voice,
and video services.
Figure 4 shows the appearance of the MA5608T.
Figure 4 Appearance of the MA5608T configured with the xPON boards| Item | MA5608T |
| Board configuration | 2 slots for control boards |
| 2 slots for service boards |
| 1 slots for the power interface board. |
| Switching capacity of the backplane bus | 720 Gbit/s |
| Supported control board and its switching capacity | MCUD/MCUD1: 128 Gbit/s in active/standby mode or 256 Gbit/s in
load-sharing mode |
| System Layer 2 packet forwarding rate | MCUD/MCUD1: 128 Gbit/s in active/standby mode or 256 Gbit/s in
load-sharing mode |
| Switching/Forwarding delay | Short forwarding delay: The 100 Mbit/s Ethernet port sends the
64-byte Ethernet packets at a delay shorter than 20 μs. |
| BER in full load | BER of a port when the port transmits data in full load < 10 e-7 |
| System reliability specifications | System: redundant configuration. |
| System availability for the typical configuration: > 99.999% |
| Mean time between failures (MTBF): about 45 years. |
| NOTE: |
| Due to different network environments and different boards used by
devices, the above-mentioned MTBF (45 years) of the MA5608T is only
for reference. The average repair time for field replaceable units
(FRUs) is about 2 hours. The preceding values are only for
reference. For details, contact the related Huawei engineers. |
| Maximum number of ADSL2+ ports in a subrack | 128 |
| Maximum number of VDSL2 ports in a subrack | 128 |
| Maximum number of EFM SHDSL ports in a subrack | 64 |
| Maximum number of TDM SHDSL ports in a subrack | 32 |
| Maximum number of POTS ports in a subrack | 128 |
| Maximum number of ISDN BRA ports in a subrack | 64 |
| Maximum number of ISDN PRA ports in a subrack | 64 |
| Maximum number of GPON ports in a subrack | 32 |
| Maximum number of 10G GPON ports in a subrack | 8 |
| Maximum number of P2P FE ports in a subrack | 96 |
| Maximum number of P2P GE ports in a subrack | 96 |
| Operating environment | Operating temperature: -40°C to +65°C |
| Operating humidity: 5% RH to 95% RH |
| Atmospheric pressure: 61 kPa to106 kPa |
| Altitude: ≤ 4000 m |
