| Ask Lasest Price | |
| Brand Name : | ZTE |
| Model Number : | F601-- |
| Certification : | CE ROHS Anatel |
| Price : | Negociatable |
| Payment Terms : | T/T,Western Union |
| Supply Ability : | 10000pcs/Week |
| Delivery Time : | 7-15days |
| Item | Parameters | Specification |
Interface | PON Port | 1 GPON optical interface Meet 1000BASE-PX20+ standard Symmetric 1.25Gbps upstream/downstream SC single-mode fiber split ratio: 1:64 Transmission distance 20KM |
Ethernet Port(LAN) | 1*GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45, Auto-MDI/MDI-X Transmission Distance 100 Meter | |
| Power Supply Port | 12V DC input | |
Management | NetworkManagement | Support IEEE802.3 QAM, ONU can be remotely managed by OLT Support Remote management through SNMP and Telnet Local management |
| Management Function | Status monitor, Configuration management, Alarm management, Log management | |
Environmental | Shell | Plastic casing |
Power | External 12V 0.5A AC/DC power supply adapter Power consumption: <3W | |
Dimensions | 78mm(L) x78mm(W) x25mm (H) 0.1kg | |
Environment | Operating Temperature:0~50℃ StorageTemperature:-40~85℃ Operating Humidity:10%~90%(Non-condensing) StorageHumidity:5%~95%(Non-condensing) |
|
|
